Preview: Zylinder Kit Miniterm 70ccm Bohrung 45mm 6 Kanäle Auslass 32mm für Zündapp (720000)

Zylinder Kit Miniterm 70ccm Bohrung 45mm 6 Kanäle Auslass 32mm für Zündapp (720000)

Cylinder set 70cc 45mm (6 ÜS) for Zündapp Minitherm CS Hai 25 448 / ZD ZL ZX 25 446 460 / GTS C 50 Sport 517 529

Rate

£172.41 *

Content: 1 piece

Prices plus VAT plus shipping costs

Unfortunately, this item is already sold out due to high demand.

Further variants / accessories

Zylinder Set 70ccm 45mm (6 ÜS) für Zündapp Minitherm CS Hai 25 448 / ZD ZL ZX 25 446 460 / GTS C 50 Sport 517 529

Zylinder Set 50ccm 39mm (4 ÜS) für Zündapp Minitherm CS Hai 25 448 / ZD ZL ZX 25 446 460 / GTS C 50 Sport 517 529

Item no: 007100
EAN: 8052204292011
Manufacturer: Athena
Manufacturer no.: 007100

Cylinder set 70cc 45mm (6 ÜS) for Zündapp Minitherm CS Hai 25 448 / ZD ZL ZX 25 446 460 / GTS C... more

Close menu

Cylinder set 70cc 45mm (6 ÜS) for Zündapp Minitherm CS Hai 25 448 / ZD ZL ZX 25 446 460 / GTS C 50 Sport 517 529

Product type:	Cylinder set
Piston pin diameter:	12 mm
Displacement:	70 ccm
Can the original cylinder head be used?:	Yes
Tuning & Styling Part:	Yes
Piston ring profile:	Rectangular ring
Vintage part:	Yes
Piston special feature:	With two 3.5x7mm piston window bores / piston ring chrome-plated.
Surface finish:	Matt
Cylinder special feature:	Nikasil-coated piston track
Inlet inside dimension:	17 x 30 mm, square
Outlet Outer dimension:	32 mm
ATTENTION!:	TUNING: Not permitted in the area of the StVZO!
GTIN:	8052204292011
Inlet stud spacing:	45 mm
Inlet stud bolt thread:	M6
Diffuser internal dimension:	27 mm
Cylinder dimensions (LxWxH):	140 x 160 x 90 mm
Scope of delivery:	Gasket set, Piston, Piston rings, Cylinder
Cylinder stud distance:	45 x 45 mm
Number of overflows:	6
Comparison number:	Athena 007100
Cylinder stud bore:	8 mm
Manifold connection type:	Clamp/plug
Color:	Grey
Number of piston rings:	1
Features:	Durable, Corrosion resistant
Engine type:	2-stroke
Scope of delivery:	1x cylinder set
Manufacturer number:	007100
Country and region of manufacture:	Italy
Type of motorcycle:	Moped & Mokick
Offer package:	Yes
Units quantity:	1
Description of the package content:	Cylinder + piston + gasket set
Manufacturer warranty:	2 years
Weight:	2.10 kg
Material:	Aluminum
Type:	Tuning
suitable for:	Zündapp Minitherm
