Jeu de cables Bowden gris for Zundapp RS 50 type 561-004 (jusqu'au FG n° 700...
Prices plus VAT plus shipping costs
IN STOCK - Delivery time 1-3 working days
Last article - Buy now
Further variants / accessories
- Item no: 168505
- EAN: 4060861188626
- Manufacturer: Citomerx
- Manufacturer no.: 168505
Zündapp Original-/Vergleichsnummer:
561-17.603 (Gaszug)
561-17.601 (Bremszug)
561-17.602 (Kupplungszug)
561-17.901 (Schaltzug)
TECHNISCHE DATEN:
- Farbe: Grau
- Material Hülle: PVC
- Material Seil: Stahl
- Hinweis: Bitte Aufnahmen und Länge vergleichen!
GASZUG
- Länge Hülle: 1660 mm
- Länge Seil: 1720 mm
- Durchmesser Hülle: 5,3 mm
- Durchmesser Seil: 1,5 mm
- Aufnahme 1: Birnennippel Ø3,2 x 5,2 mm
- Aufnahme 2: Birnennippel Ø3,2 x 5,2 mm
- Bowdenzug Öler: Ja
BREMSZUG
- Länge Hülle: 1070 mm
- Länge Seil: 1200 mm
- Durchmesser Hülle: 5,3 mm
- Durchmesser Seil: 1,5 mm
- Aufnahme 1: Birnennippel Ø6 x 14 mm
- Aufnahme 2: Birnennippel Ø6 x 8 mm
- Bowdenzugspanner: 1x M6-Gewinde
- Besonderheit: Haltenippel Ø8x9 mm / mit Gummitülle für Bowdenzugspanner
- Bowdenzug Öler: Ja
KUPPLUNGSZUG
- Länge Hülle: 1390 mm
- Länge Seil: 1500 mm
- Durchmesser Hülle: 5,3 mm
- Durchmesser Seil: 1,8 mm
- Aufnahme 1: Tonnennippel Ø6 x 7,5 mm
- Aufnahme 2: Tonnennippel Ø8 x 12 mm
- Bowdenzugspanner: 1x M6-Gewinde
- Besonderheit: mit Umlenkung (motorseitig)
- Bowdenzug Öler: Ja
SCHALTZUG
- Länge Hülle: 1300 mm
- Länge Seil: 1470 mm
- Durchmesser Hülle: 5,3 mm
- Durchmesser Seil: 1,5 mm
- Aufnahme 1: Tonnennippel Ø8 x 12 mm
- Aufnahme 2: Tonnennippel Ø8 x 12 mm
- Bowdenzugspanner: 1x M6-Gewinde
- Besonderheit: Halter (motorseitig) / Haltenippel Ø7x6 mm
- Bowdenzug Öler: Ja
LIEFERUMFANG:
1x Bowdenzug Satz
Zündapp RS 50 Typ 561-004 (bis FG-Nr. 7003305)
| OE/OEM reference number(s): | 561-17.601 (brake cable), 561-17.602 (clutch cable), 561-17.603 (throttle cable), 561-17.901 (shift cable) |
| Clutch cable rope diameter: | 1.8 mm |
| Brake cable Special feature: | Retaining nipple Ø8x9 mm / with rubber grommet for Bowden cable tensioner |
| Brake cable Bowden cable oiler: | Yes |
| Brake cable length Cover: | 1070 mm |
| Brake cable length Cable (total length): | 1200 mm |
| Throttle cable mount 1: | Pear nipple Ø3.2 x 5.2 mm |
| Throttle cable diameter cover: | 5.3 mm |
| Throttle cable length cover: | 1660 mm |
| Throttle cable length Cable (total length): | 1720 mm |
| Clutch cable mount 2: | Barrel nipple Ø8 x 12 mm |
| Clutch cable Special feature: | with deflection (motor side) |
| Clutch cable length cover: | 1390 mm |
| Throttle cable mount 2: | Pear nipple Ø3.2 x 5.2 mm |
| Clutch cable length Cable (total length): | 1500 mm |
| Restriction vehicle: | up to FG-No. 7003305 |
| Shift cable mount 1: | Barrel nipple Ø8 x 12 mm |
| Shift cable special feature: | Holder (motor side) / retaining nipple Ø7x6 mm |
| Shift cable Bowden cable oiler: | Yes |
| Shifter cable diameter cover: | 5.3 mm |
| Shift cable length cover: | 1300 mm |
| Shift cable length Cable (total length): | 1470 mm |
| Brake cable mount 1: | Pear nipple Ø6 x 14 mm |
| Clutch cable mount 1: | Barrel nipple Ø6 x 7.5 mm |
| Cover material: | PVC |
| Shift cable diameter Cable: | 1.5 mm |
| Universal compatibility: | No |
| Vintage part: | Yes |
| Clutch cable Bowden cable oiler: | Yes |
| Rope material: | Steel |
| Tuning & Styling Part: | No |
| Shift cable Bowden cable tensioner: | 1x M6 thread |
| Brake cable mount 2: | Pear nipple Ø6 x 8 mm |
| Brake cable diameter Cable: | 1.5 mm |
| Brake cable diameter cover: | 5.3 mm |
| Throttle cable diameter rope: | 1.5 mm |
| Brake cable Bowden cable tensioner: | 1x M6 thread |
| Throttle cable Bowden cable oiler: | Yes |
| Clutch cable Bowden cable tensioner: | 1x M6 thread |
| Clutch cable diameter cover: | 5.3 mm |
| Shift cable mount 2: | Barrel nipple Ø8 x 12 mm |
| Note: | Please compare recordings and length! |
| Color: | Grey |
| Scope of delivery: | 1x Bowden cable set |
| Manufacturer number: | 168505 |
| Country and region of manufacture: | China |
| Brand compatibility: | Zündapp |
| Product type: | Bowden cable set |
| Type of motorcycle: | Scooter |
| Offer package: | Yes |
| Description of the package content: | Throttle / brake / clutch / shift cable |
| Manufacturer warranty: | 2 years |
