Jeu de cables Bowden gris for Zundapp GTS 50 type 517-35LA (jusqu'au FG n° 5...
Prices plus VAT plus shipping costs
Unfortunately, this item is already sold out due to high demand.
- Item no: 168471
- EAN: 4060861188268
- Manufacturer: Citomerx
- Manufacturer no.: 168471
Zündapp Original-/Vergleichsnummer:
517-17.682 (Gaszug)
517-17.640 (Bremszug)
514-17.608 (Kupplungszug)
TECHNISCHE DATEN:
- Produktart: Bowdenzug Set
- Farbe: Grau
- Material Hülle: PVC
- Material Seil: Stahl
- Hinweis: Bitte Aufnahmen und Länge vergleichen!
GASZUG
- Länge Hülle: 755 mm
- Länge Seil (Gesamtlänge): 880 mm
- Durchmesser Hülle: 4,8 mm
- Durchmesser Seil: 1,2 mm
- Aufnahme 1: Tonnennippel Ø5 x 7 mm
- Aufnahme 2: Birnennippel Ø3 x 3 mm
- Bowdenzugspanner: 1x M6-Gewinde
- Bowdenzug Öler: Nein
BREMSZUG
- Länge Hülle: 950 mm
- Länge Seil (Gesamtlänge): 1085 mm
- Durchmesser Hülle: 4,8 mm
- Durchmesser Seil: 1,5 mm
- Aufnahme 1: Birnennippel Ø6 x 10 mm
- Aufnahme 2: Birnennippel Ø6 x 10 mm
- Bowdenzugspanner: 2x M6-Gewinde
- Bowdenzug Öler: Nein
KUPPLUNGSZUG
- Länge Hülle: 955 mm
- Länge Seil (Gesamtlänge): 1050 mm
- Durchmesser Hülle: 4,9 mm
- Durchmesser Seil: 1,5 mm
- Aufnahme 1: Birnennippel Ø5,8 x 10 mm
- Aufnahme 2: Tonnennippel Ø6 x 8 mm
- Bowdenzugspanner: 2x M6-Gewinde
- Bowdenzug Öler: Nein
LIEFERUMFANG:
1x Bowdenzug Satz
Zündapp GTS 50 Typ 517-35LA (bis FG-Nr. 5859863)
| Product type: | Bowden cable set |
| Brake cable front diameter cover / cable: | 5.0 / 1.5 mm |
| Restriction vehicle: | up to FG-No. 5859863 |
| Rope material: | Steel |
| Front brake cable Length of sheath / cable: | 950 / 1085 mm |
| Tuning & Styling Part: | No |
| Cover material: | PVC |
| Vintage part: | Yes |
| Clutch cable diameter cover / cable: | 5.0 / 1.5 mm |
| Throttle cable diameter sheath / cable: | 5.0 / 1.3 mm |
| Universal compatibility: | No |
| Model compatibility: | Zündapp |
| Clutch cable length cover / cable: | 955 / 1050 mm |
| OE/OEM reference number(s): | 514-17.608 (clutch cable), 517-17.682 (throttle cable), 517-17,640 (brake cable) |
| GTIN: | 4060861188268 |
| Throttle cable length sheath / cable: | 755 / 880 mm |
| Note: | Please compare recordings and length! |
| Color: | Grey |
| Scope of delivery: | 1x Bowden cable set |
| Manufacturer number: | 168471 |
| Country and region of manufacture: | China |
| Brand compatibility: | Zündapp |
| Installation position: | Right, Links |
| Type of motorcycle: | Road motorcycle |
| Offer package: | Yes |
| Description of the package content: | Throttle / brake / clutch cable |
| Manufacturer warranty: | 2 years |
