Jeu de cables Bowden noir pour Zundapp ZD 40 type 446-300 (jusqu'au FG n° 912...
Prices plus VAT plus shipping costs
IN STOCK - Delivery time 1-3 working days
Only a few left!
- Item no: 168436
- EAN: 4060861187889
- Manufacturer: Citomerx
- Manufacturer no.: 168436
Zündapp Original-/Vergleichsnummer:
447-17.613 (Gaszug)
446-17.615 (Bremszug)
446-17.614 (Kupplungszug)
TECHNISCHE DATEN:
- Produktart: Bowdenzug Set
- Farbe: Schwarz
- Material Hülle: PVC
- Material Seil: Stahl
- Hinweis: Bitte Aufnahmen und Länge vergleichen!
GASZUG
- Länge Hülle: 770 mm
- Länge Seil (Gesamtlänge): 910 mm
- Durchmesser Hülle: 4,8 mm
- Durchmesser Seil: 1,3 mm
- Aufnahme 1: Tonnennippel Ø5,2 x 7 mm
- Aufnahme 2: Birnennippel Ø3 x 3,5 mm
- Bowdenzugspanner: 1x M6-Gewinde
- Besonderheit: mit Umlenkung (motorseitig)
- Bowdenzug Öler: Ja
BREMSZUG
- Länge Hülle: 885 mm
- Länge Seil (Gesamtlänge): 1000 mm
- Durchmesser Hülle: 4,8 mm
- Durchmesser Seil: 1,5 mm
- Aufnahme 1: Birnennippel Ø6 x 10 mm
- Aufnahme 2: Birnennippel Ø6 x 10 mm
- Bowdenzugspanner: 1x M6-Gewinde
- Bowdenzug Öler: Nein
KUPPLUNGSZUG
- Länge Hülle: 930 mm
- Länge Seil (Gesamtlänge): 1000 mm
- Durchmesser Hülle: 5,3 mm
- Durchmesser Seil: 1,5 mm
- Aufnahme 1: Birnennippel Ø6 x 8 mm
- Aufnahme 2: Tonnennippel Ø6 x 7,5 mm
- Bowdenzugspanner: 1x M6-Gewinde
- Bowdenzug Öler: Nein
LIEFERUMFANG:
1x Bowdenzug Satz
Zündapp ZD 40 Typ 446-300 (bis FG-Nr. 9120744)
| OE/OEM reference number(s): | 446-17.614 (clutch cable), 446-17.615 (brake cable), 447-17.613 (throttle cable) |
| Throttle cable mount 1: | Barrel nipple Ø5.2 x 7 mm |
| Cover material: | PVC |
| Rope material: | Steel |
| Brake cable length Cover: | 885 mm |
| Throttle cable length cover: | 770 mm |
| Throttle cable length Cable (total length): | 910 mm |
| Brake cable Bowden cable tensioner: | 1x M6 thread |
| Throttle cable mount 2: | Pear nipple Ø3 x 3.5 mm |
| Throttle cable Special feature: | with deflection (motor side) |
| Throttle cable Bowden cable oiler: | Yes |
| Throttle cable diameter rope: | 1.3 mm |
| Clutch cable mount 1: | Pear nipple Ø6 x 8 mm |
| Clutch cable mount 2: | Barrel nipple Ø6 x 7.5 mm |
| Clutch cable Bowden cable tensioner: | 1x M6 thread |
| Clutch cable diameter cover: | 5.3 mm |
| Brake cable length Cable (total length): | 1000 mm |
| Clutch cable rope diameter: | 1.5 mm |
| Clutch cable length Cable (total length): | 1000 mm |
| Brake cable mount 1: | Pear nipple Ø6 x 10 mm |
| Restriction vehicle: | up to FG-No. 9120744 |
| Tuning & Styling Part: | No |
| Vintage part: | Yes |
| Universal compatibility: | No |
| Brake cable mount 2: | Pear nipple Ø6 x 10 mm |
| Clutch cable Bowden cable oiler: | No |
| Brake cable Bowden cable oiler: | No |
| Brake cable diameter cover: | 4.8 mm |
| Brake cable diameter Cable: | 1.5 mm |
| Throttle cable Bowden cable tensioner: | 1x M6 thread |
| Throttle cable diameter cover: | 4.8 mm |
| Note: | Please compare recordings and length! |
| Clutch cable length cover: | 930 mm |
| Color: | Black |
| Scope of delivery: | 1x Bowden cable set |
| Manufacturer number: | 168436 |
| Country and region of manufacture: | China |
| Brand compatibility: | Zündapp |
| Product type: | Bowden cable set |
| Type of motorcycle: | Road motorcycle |
| Offer package: | Yes |
| Description of the package content: | Throttle / brake / clutch cable |
| Manufacturer warranty: | 2 years |
