Battery charger for lithium-ion batteries in motorcycles and scooters
£23.49 *
Content:
1 piece
Prices plus VAT plus shipping costs
IN STOCK - Delivery time 1-3 working days
- Item no: 164101
- EAN: 4251048814289
- Manufacturer: Citomerx
- Manufacturer no.: 164101
- Weight: 0.141 kg
Citomerx battery charger for lithium-ion batteries for motorcycles and scooters
DESCRIPTION:... more
Product information about Battery charger for lithium-ion batteries in motorcycles and scooters
Citomerx battery charger for lithium-ion batteries for motorcycles and scooters
DESCRIPTION:
Charger for Lithium- Iron Phosphate batteries (LiFePO4) for various motorized two-wheelers (motorcycle, scooter, ATV/ Quad), based on a two-stage charging system ("CC to CV"). When charging a LI- battery, the charger first delivers a constant current charge. Thus the battery quickly reaches the specified final charging voltage. The charger then switches to a constant voltage mode to continue charging the battery continuously.
TECHNICAL DATA:
- especially for charging lithium-ion batteries with iron phosphate cathodes, so-called LiFePO4 batteries
- LED display (red: battery is charging, green: battery is fully charged)
- Input voltage: AC 100-240 V, 50-60 Hz
- Constant voltage: 14.6 V
- Constant current: 1.0 A
- Dimensions of the connector part: approx. 80x53x34 mm
- Length of the battery terminals: approx. 80 mm
- max. opening width of the battery terminals (max. diameter of the battery poles): approx. 28 mm
- Material (cover): plastic
PROCEDURE FOR CHARGING THE BATTERY:
- Connect the charger to the battery. Observe the "positive (+ red) and negative (- black) poles".
- Only then connect the charger to the mains socket.
SAFETY INSTRUCTIONS:
- Use the charger indoors if possible and never in rain or wet conditions!
- When the battery is charged, first remove the plug from the socket. Then remove the charger from the battery.
- Do not use the device near explosive gases or sparks. When charging, the charger should be stored in a well-ventilated room to avoid overheating.
- Use the unit only with 12V lithium batteries. (For example, if the charger is used for 10V batteries, the battery may explode).
SCOPE OF DELIVERY:
✔ Citomerx Battery Charger for Lithium Ion Batteries
DESCRIPTION:
Charger for Lithium- Iron Phosphate batteries (LiFePO4) for various motorized two-wheelers (motorcycle, scooter, ATV/ Quad), based on a two-stage charging system ("CC to CV"). When charging a LI- battery, the charger first delivers a constant current charge. Thus the battery quickly reaches the specified final charging voltage. The charger then switches to a constant voltage mode to continue charging the battery continuously.
TECHNICAL DATA:
- especially for charging lithium-ion batteries with iron phosphate cathodes, so-called LiFePO4 batteries
- LED display (red: battery is charging, green: battery is fully charged)
- Input voltage: AC 100-240 V, 50-60 Hz
- Constant voltage: 14.6 V
- Constant current: 1.0 A
- Dimensions of the connector part: approx. 80x53x34 mm
- Length of the battery terminals: approx. 80 mm
- max. opening width of the battery terminals (max. diameter of the battery poles): approx. 28 mm
- Material (cover): plastic
PROCEDURE FOR CHARGING THE BATTERY:
- Connect the charger to the battery. Observe the "positive (+ red) and negative (- black) poles".
- Only then connect the charger to the mains socket.
SAFETY INSTRUCTIONS:
- Use the charger indoors if possible and never in rain or wet conditions!
- When the battery is charged, first remove the plug from the socket. Then remove the charger from the battery.
- Do not use the device near explosive gases or sparks. When charging, the charger should be stored in a well-ventilated room to avoid overheating.
- Use the unit only with 12V lithium batteries. (For example, if the charger is used for 10V batteries, the battery may explode).
SCOPE OF DELIVERY:
✔ Citomerx Battery Charger for Lithium Ion Batteries
Further links to "Battery charger for lithium-ion batteries in motorcycles and scooters"
Sicherheitsinformationen für dieses Produkt. more
MANUFACTURER INFORMATION FOR THE EU:
Brand name: Citomerx
INFORMATION ON THE PERSON RESPONSIBLE FOR THE EU:
Available downloads:
Properties more
| GTIN: | 4251048814289 |
| Input voltage: | AC 100-240 V, 50-60 Hz |
| Constant voltage: | 14,6 V |
| Constant current: | 1,0 A |
| Length of the battery terminals: | 80 mm |
| Dimensions of the connector part: | 80 x 53 x 34 mm |
| Opening width of the battery terminals: | 28 mm |
| Color: | Black |
| Reference number(s) OEM: | Battery Battery charger Battery, Battery charger Charger Charging, battery charger load loading recharge,, Battery maintainer |
| Manufacturer number: | 164101 |
| Manufacturer warranty: | 2 years |
| Material: | Plastic |
